Custom Shop Drawings – Design Verification Before Production
Our Custom Shop Drawings provide detailed, to-scale illustrations of your door unit before it goes into production. These professional design documents are essential for confirming specifications, coordinating with contractors, and ensuring your custom door is built exactly to your needs.
What’s Included:
-
Precise overall unit dimensions
-
Door style and configuration
-
Stile and rail profiles
-
Panel and glass layouts (if applicable)
-
Jamb and threshold details
-
Swing/handing direction
-
Hardware prep details (if required)
Why It’s Required:
Creating these drawings requires time, expertise, and careful attention to detail. This ensures your door is made to your exact specifications, with no surprises during production or installation.
-
Cost: $350 includes up to 2 sets of shop drawings
-
Additional drawings (for variations or multiple units): $125 each
-
Credit: The $350 will be fully credited toward your final door order
⚠️ Important Note: Drawing fees are non-refundable if you decide not to move forward with your order, as each drawing set involves custom design work.
We are happy to provide this service to support your planning process and ensure the highest quality results—but please note, we do not offer free design or drawing services.
